MERCURY LED 10 SLW Ex
archive
archive
MERCURY LED 10 SLW Ex
10 Wluminaire power
1100 lmlight flow
110 lm/Wenergy efficiency
code1502000760
color temperature4000
gas marking2 Ex nR II T6 Gc
dust markingEx tb IIIC T80 C Db
weight7 kg
options
свернуть все
illuminatingelectricalconstructionalexplosion-proofemergencycommon
Synchronization of flashing mode
Нетcolor rendition index (CRI)
>75light flow
1100 lmenergy efficiency
110 lm/Wflickering factor
<1%color temperature
4000light source type
LEDemission color
Белыйilluminating
Synchronization of flashing mode
Нет
color rendition index (CRI)
>75
light flow
1100 lm
energy efficiency
110 lm/W
flickering factor
<1%
color temperature
4000
light source type
LED
emission color
Белый
electrical
electric shock protection
I
supply voltage, alternating current
176-264 V
maximum cross-section of the connected cable, sq. mm
2.5
starting current pulse time, µs
140 mks
luminaire power
10 W
power factor
> 0,93
starting current
26 A
constructional
weight
7 kg
length, mm
410 mm
width, mm
262 mm
height, mm
183 mm
installation length, mm
220 mm
material
Сталь нержавеющая
fire safety class
П-ІІ
climatic performance
УХЛ2*
shock resistance (IK)
IK08/7 Дж
housing color
Серый
explosion-proof
gas marking
2 Ex nR II T6 Gc
dust marking
Ex tb IIIC T80 C Db
gas explosion-proof (type)
Ex nR
gas explosion-proof (zones)
2
gas explosion-proof (groups of equipment)
II
T6 - temperature class
T6
emergency
operating time in emergency mode, hours
3 h
type of operation / type of operation of the emergency luminaire
постоянного действия
battery / battery Ni-Cd
RB 6,4 V 6,0 A*h LiFePO4
common
code
1502000760
warranty
36 month
temperature range
от 0 до +55 C
energy efficiency class
A+
service life, hour
50 000 h
ETIM class
Светильник взрывобезопасный/взрывозащищенный стационарный (фиксиров. установки)
model files
model files
documents
сертификаты
documents
passport461.9 kB
сертификаты
Certificate of Russian maritime register of shipping1.5 mB
Certificate of conformity TRTS 012/20112.2 mB
Declaration of Conformity TRTS 020/2011201.4 kB
Certificate of seismic resistance834.7 kB
Declaration of Conformity EAEU TR 037/2016197.5 kB
Fire Safety Certificate471.1 kB
